Water Quality Monitoring

Innovative Tailored Water Quality Monitoring Solutions

Trust 47-years of water industry expertise. Our technical team are ready to assess what you need, specify a solution, and deliver a complete package to meet your exact water quality monitoring requirements. We are s::can’s exclusive partner in Ireland – a global leader in water monitoring technology.

Product Range

Spectrometer Probes

A range of online sensors for drinking water and wastewater applications. The first and only instruments in the world that can measure optical spectra from 190 to 750 nm directly in liquid media. Measuring across the total UV-Vis range, with monitoring including: total suspended solids, turbidity, NO3-N, COD, BOD, TOC, DOC, UV254, NO2-N, colour, O3, HS-, BTX, AOC, fingerprints and spectral alarms, temperature and pressure.
water-quality-monitoring
  • spectro::lyser v3
    Measures the entire UV-Vis absorption spectrum (190-750nm) and is used in both drinking water and wastewater applications. Fully submersible, IoT enabled, has large onboard data storage capacity, and requires no additional software.
    View product
  • spectro::lyser titanium pro
    UV-Vis spectrometry over the total range (190-720 nm), highly resistant titanium grade 2 housing, up to 10 bar operating pressure. Ideal for wastewater, desalination and sea water.
    View product
  • spectro::lyser industrial ATEX
    UV-Vis spectrometry over the total range (190-720 nm), explosion proof specification, up to 10 bar operating pressure. Ideal for industrial wastewater and sewer applications.
    View product
  • spectro::lyser UV
    UV-Vis spectrometry over the total range (190-390 nm). Ideal for surface water, ground water, drinking water and wastewater.
    View product
  • i::scan
    The new miniature multi-parameter spectrophotometer probe will revolutionize online water quality monitoring, from very cost sensitive applications down to highly resolved “Smart Water Grids”, in small unmanned plants, or even in single building protection.
    View product
  • carbo::lyser V3
    Ideal for the measurement of the organic carbon load and turbidity / solids concentration. Ideal uses range from pure water to industrial wastewater.
    View product
  • ozo::lyser V3
    For measuring concentrations of ozone dissolved in water. Low maintenance, extreme stability, fast measurement intervals. Ideal for wastewater, surface water and drinking water.
    View product
  • nitro::lyser V3
    Applications range from (ultra) pure water in the μg/l range up to industrial wastewater in the g/l range. The nitrate concentration displayed is not sensitive to cross-influences from organic carbon or total solids.
    View product
  • multi::lyser V3
    A combination of s::can carbo::lyser and nitro::lyser. For measuring organic carbon & nitrate for a multitude of pre-defined applications. Ideal for surface water, ground water, drinking water, and wastewater.
    View product
  • uv::lyser V3
    Monitors turbidity or TSS and up to 4 freely chosen wavelengths between 190 and 720 nm. Depending on the application, it also measures turbidity or solids. Ideal for surface water, ground water, drinking water, and wastewater.
    View product

Other Sensors

A range of high-tech sensors that measure a huge variety of parameters including chlorine, concentration of dissolved oxygen, ammonium, fluoride, potassium, conductivity, pH, total suspended solids, and more.
water-quality-monitoring

Terminals & Software

A range of terminals and software designed to help you make the most of the data collected by online sensors. The innovative software enables complete data acquisition, station control, and empowers users to make fully informed, data driven actions. With products that feature IoT connectivity, intuitive operation, alarm triggers, automatic data validation, anomaly identification, sensor and station management for multiple parameters, and more. The ideal solution for data acquisition and station control.
water-quality-monitoring
  • con::cube V3
    A compact, versatile terminal for data acquisition and station control. IoT and machine to machine ready, with intuitive use, information visualisation and easy operation. Flexible options for interfacing to SCADA or any central database systems.
    View product
  • con::lyte
    The terminal con::lyte displays the readings of all s::can probes & sensors connected on site via backlight LCD. A simple, user-friendly, low-cost terminal designed for control applications, for sensor and station management of up to two (eco) or six (pro) parameters.
    View product
  • visu::tool
    visu::tool is a fast and easy-to-use data visualization software for PCs and notebooks. In 3 simple steps you can visualize huge amounts of data from con::cube or con::lyte into single or multiple graphs. Ability to create customised reports.
    View product
  • moni::tool
    View product
  • vali::tool
    View product
  • ana::tool
    View product
  • lo::tool
    View product
  • con::nect V3
    View product
  • con::nect
    View product

Monitoring Stations

A range of monitoring stations designed for the online monitoring of water quality parameters in waste and clean water. The fully modular stations combine s::can instruments in a versatile system, with all required components, including probes and controllers, factory assembled, with associated flow cells, mounting fittings and pipework, on a compact panel. A complete solution, with the user only required to connect water supply and discharge.
water-quality-monitoring
  • micro::station for drinking water
    Designed for online monitoring of water quality parameters in clean media. Components are factory assembled with all required flow cells, associated flow cells, mounting fittings and pipework, on a compact panel.
    View product
  • micro::station for wastewater
    Designed for online monitoring of water quality parameters in waste water. Components are factory assembled with all required flow cells, associated flow cells, mounting fittings and pipework, on a compact panel.
    View product
  • nano::station
    A monitoring solution for many different applications: From very cost sensitive applications down to highly resolved "Smart Water Grids", in small unmanned plants, or even in single building protection. Fully modular, super-compact system.
    View product

pipe::scan

The pipe::scan is a modular sensor system for monitoring drinking water quality in pipes under pressure. Mounted directly on the pipe, it measures up to 10 parameters in one device: TOC, DOC, UV254, turbidity, colour, chlorine, pH/redox, conductivity, temperature and pressure. The water quality data can be sent to any central database via almost any protocol. Multiple pipe::scans are the ideal solution to monitor drinking water at any point in the network.
water-quality-monitoring

Accessories

A wide range of accessories including extension cables for probes, flow cells, electrodes, compressors, carriers, power cords, weather shields, field cases, cleaning agents, and more.

Contact

How Can We Help?

Contact our team of technical experts today. Whether it be water treatment, monitoring or purification, we’ll help to advise and guide on the best solution for your needs.
